Component of Mechanical Standard Refrigeration System
Control panel device component of standard refrigeration system
Pressure Switch of standard refrigeration system
Magnetic Contactor
Structure of DA100 Program
-
Diagram of Standard Refrigeration System: Compressor → Condenser → Filter Dryer → Sight Glass → Solenoid Valve → Manual Expansion Valve → Evaporator → Compressor
-
Measuring of Temperature, Pressure, Enthalpy
-
Drawing P-h diagram on real time
-
Refrigerating effect (qe), Compressor work (Aw), Condensation effect (qc), Coefficient of Performance (COP)
-
Feature of save data
-
Feature of capture for P-h diagram
-
Features of DA100 program
-
Monitoring the measured data of temperature and pressure in real time
-
Monitoring the measured data of enthalpy on a refrigeration system in real time
-
Monitoring factors like as refrigeration effect, compressor work, evaporating, latent heat, amount of falssh gas at expansion valve outlet, dry ratio at expansion valve outlet, coefficient of performance in the abstract with temperature and pressure data which are measured in real time
-
Being saved data all temperature, pressure and enthalpy as excel micro office
-
Experiment for drawing a P-h diagram as measured temperature and pressure
-
Refrigeration cycle
Video clips for introduction
Introduction to Refrigeration & HVAC System and Education Curriculum
